The Datavideo PTR-15 represents their latest innovation, boasting a 4K 12G-SDI motorized remote pan-tilt head with integrated FreeD functionality. Its advanced drive system ensures precise and fluid pan and tilt motions.
Compatible with a wide range of professional broadcast cameras, it enables remote control of essential parameters like pan, tilt, zoom, and aperture adjustments.
The PTR-15 finds versatile applications across fields such as sports events, concerts, live broadcasting, venue video installations, high-end video conferencing, and emergency information systems.
Control options encompass IR controllers, VISCA protocol controllers, Datavideo RMC-180 MARK II camera controllers, and RMC-300A universal remote control panels. The system is compatible with both serial and Ethernet (DVIP) connections, offering flexible control solutions.
PTR-15 поддерживает многие сигнальные интерфейсы, служащие для прохода через выносной блок. Среди них — SDI, HDMI, RS-232, RS-422, DVIP, Tally и LANC.
Суперпрочная конструкция PTR-15 изготовлена из алюминиевого сплава, обеспечивающего надежность крепления камеры.
In addition to the standard RS-232/422 control, the PTR-15 provides robust IP-based control, keeping up with the modern trend of IP-based systems. This technology migrates the camera control protocols and technical parameter adjustments used in high-end broadcast studios to an open IP environment. This transformation breaks away from the previous limitations of exclusive one-to-one control, enabling the free switching of different cameras and achieving precise adjustments of camera parameters such as aperture, shutter, red/blue gain, inflection point, and more. This advancement allows on-site camera operations to enter an unprecedented era of convenience.
The robust and stable nature of SDI interfaces makes them highly suitable for broadcast environments, while HDMI offers high compatibility with peripheral devices. The PTR-15 fully supports both 12G-SDI and HDMI 2.0 standards for broadcast and AV applications. Whether you require SDI or HDMI connections, it provides a complete 4K50/60P audiovisual transmission channel.
This is one of the criteria that differentiates broadcast-grade equipment from regular cameras. The genlock function allows interconnection of all cameras and display devices, ensuring precise synchronization at every frame, all operating on the same clock frequency. This prevents issues like tearing due to unstable frame transmission.
The timecode calibration function enables the interconnection of all cameras and recording devices, providing the same time parameters. This establishes a unified time reference point for subsequent archiving or post-production, ensuring consistency.
Если для создания видео требуется множество различных ракурсов и положений, 199 предустановленных положений камеры удовлетворят ваши потребности.
С помощью инфракрасного пульта дистанционного управления можно вызывать до 199 предустановленных положений в любой момент.
При использовании в сочетании с универсальным контроллером дистанционного управления RMC-300A в любой момент можно задействовать 14 физических кнопок.
При использовании пульта дистанционного управления RMC-180 MARK II для вызова доступны 4 физические кнопки.
To cater to the diverse power requirements of various camera models, PTR-15 features a dual voltage output capability.
This design effortlessly accommodates the majority of business and professional cameras available in the market.
Switching between voltage specifications is made simple via a selector switch on the rear panel. This ensures a stable power supply with surge protection mechanisms for enhanced safety during usage.
Datavideo's PTR-15 robotic pan tilt head combines advanced pan-tilt technology with AR/VR systems. It interfaces via RS-422 to transmit pan, tilt, and zoom data to the TVS-3000 Virtual Studio Production System, ensuring seamless collaboration.
For different cameras and lenses, it supports lens tracking data acquisition via ZEK-1 or ZEK-2 sensors, enabling lens zoom control and motor tracking synchronization. The RS-422 output provides 8-bit precision Free-D protocol tracking data, compatible with most virtual systems.
It offers precise pan (±340 degrees) and tilt (±45 degrees) control with adjustable motion trajectories and speeds, achieving high precision. Built on Datavideo's DVIP protocol, it's compatible with TCP/IP network protocols, supporting third-party device control.
You can choose the RMC-300A IP control panel with a 5-inch UI touchscreen or the RMC-180 MARK II serial control panel for dual-system control, enhancing security and reliability.
Комплект для кодера зума ZEK-2 — это механическое устройство, позволяющее монтировать двигатель Tilta Nucleus-M, посредством которого добавляется функция автоматического позиционирования зума на видеокамере Panasonic Lumix BGH-1, смонтированной на роботизированной головке PTR-15 с регулируемым панорамированием и поворотом.
Established by the Ministry of Economic Affairs of Taiwan in 1993, the Taiwan Excellence Awards commend outstanding products from Taiwanese companies, showcasing the superior quality and innovation of Taiwanese manufacturing.
Winning the 2024 Taiwan Excellence Award is a significant milestone for the Datavideo PTR-15 4K Robotic Pan Tilt Head, highlighting its exceptional performance amidst a competitive field of entries.
"We are very honored that the Datavideo PTR-15 has won the 2024 Taiwan Excellence Award. This Award acknowledges Datavideo's innovation and outstanding product quality in video production industry.” said Kevin Zhang, Datavideo's General Manager.
