HD/SD PTZ Video Camera with HDBaseT Technology

Made with HDBaseT Technology

Rather than using one cable for video, a second cable for power, and a third cable for camera control, the PTC-150T is able to do all of the above using a single ethernet cable. This increase in flexibility greatly reduces setup time, and now you can mount the camera in challenging locations (like spots without nearby power outlets)

One-person camera crew



The beauty of multiple PTC-150T cameras is the ability to control all of them from a single control panel. Pair cameras with the RMC-180 controller or with one of our HDBaseT mobile switchers like the HS-1600T, and you can reduce your camera crew to just... you.

Fantastic 3G Resolution with 30x Optical Zoom



The PTC-150T shoots video at a maximum resolution of 1080p60, with advanced digital noise reduction for beautiful, smooth image quality even in less-than-perfect lighting conditions. 30x optical zoom allows you to mount it near or far and still get great, sharp shots.



Black or White Body



The PTC-150T is available in dark gray or white to remain inconspicuous in permanent setups.



''TL'' Version for Datavideo HDBaseT Switchers



The PTC-150TL (without receiver box) is available for use with Datavideo HDBaseT Switchers and Mobile Cast Studios.

PoE Compatibility List

The chart above shows the product's direct compatibility with other HDBaseT products.

Specifications

PTC-150T HD/SD PTZ Video Camera with HDBaseT Technology
Video format

1080p 59.94/50/29.97/25
1080i 59.94/50
720p 59.94/50
480i, 576i (on CVBS)

Image Sensor

1/2.8” type progressive scan CMOS sensor

Effective Pixels (approx.)

2.14 Mega pixels

S/N Ratio

50dB

Min. Illumination

Color : 0.4 lx
B/W : 0.03 lx (F1.6, 1/30 sec, 50IRE, Gain: High)

Electronic Shutter

1/25~1/1250 sec (50/25Hz)
1/30~1/1500 sec (59.94/29.97Hz)

Zoom Ratio

30x Optical Zoom

Gamma Control

Off / Normal / Standard Mode 1-4

Iris Control

Auto / Manual

Digital Noise Reductions

Yes

On-Screen Display (OSD)

English

White Balance

AWB, MWB, One push WB, Outdoor, Indoor, Fluorescent

AGC / Gain Control

Auto / Manual
Max. Gain Limit

Mirror / Flip Image

Yes

Focus Mode

Auto / Manual

Panning / Tilting Range

Pan: 270° , Tilt: +90° to -20°

Panning / Tilting Speed

Manual: 1~150°/Sec
Swing: 1~150°/Sec

Preset

50 Position

Focal Length

f=4.3 mm (WIDE) to 129 mm (TELE)
F1.6 to F4.7

Field of View (Horizontal, Wide)

Approx. 63.7° (WIDE END) / 2.3° (TELE END)

Image Compensation

Day & Night function

Video Output

HDMI (V1.3) x 1
3G-SDI x 1
CVBS x 1
HDBaseT x 1 to PTC-150T Receiver Box

Tally LED

Dual color (Red, Green)

Filter

M52.0 x 0.75 Thread with UV Protection

Protocol

VISCA, DVIP

Remote Control Interface and Transmit Distance

RS-422: Transmit up to 1000m
HDBaseT (RJ-45)/ DVIP on Receiver Box: Transmit up to 100m

F/W Update

USB

IR Control

Yes

Camera Control Unit

HS-1500T/HS-1600T/RMC-180

Tripod Mount

1/4-20 UNC

Options

WM-1/WM-10

Color

Black/White

Dimension (LxWxH)

173 x 189 x 219 mm

Weight

2.7 kg

Operating Temp. Range

0~40 °C

Power

DC 12V 29W

What's in the Box

1 x PTC-150T/TW Unit
1 x HBT-11 Receiver Box
1 x IR remote controller
1 x PTC-150T/TW Thank You Card
1 x Ceiling mount bracket-A
1 x Ceiling mount bracket-B
6 x Ceiling mount bracket screw M3*4mm
1 x DC 12V Power Adaptor
1 x DC 48V Power Adaptor
2 x Power Cord
1 x A braided safety cable
1 x Phoenix connector to RJ-45

Cable Requirement

Requires Solid Core, Cat -6 Shielded cable for Ethernet connection

Cable Recommendation
