H.264 Video Streaming Server / Recorder

Multiple input configurations

1x SDI/HDMI/CVBS input; 1x RCA L/R, 2x XLR audio input



Record on USB thumb drive

The NVS-25 can record MP4 or TS file to a USB storage device.

Specifications

NVS-25 H.264 Video Streaming Server
Video Input

HDMI x1
SDI x1
CVBS x1

Supported Video Input Resolution

1080p 50/59.94/60 (record/output at 25/30p)
1080i 50/59.94/60
720p 50/59.94/60
576i, 480i

Audio Input

RCA L/R x1
XLR x2

Encode

H.264 Main 3.0/3.1/High4.0

Video Bitrate

800Kbps~6Mbp
(The same bitrate for recording and streaming)

Video Rate Mode

CBR/VBR

Audio Mode

Stereo/Mono

Audio Bitrate

Stereo: 64~384Kbps
Mono: 32~192Kbps

Streaming Protocols

HLS
RTSP over HTTP/TCP/UDP
RTMP (Local, Publish)

Recording File Format

Transport Stream
MP4

Storage

USB x1

Power Supply

DC 12V 7.2W

Dimension (LxWxH)

220 x 143 x 47 mm

Weight

1 kg

Operating Temp. Range

0~40 °C

What's in the Box

1 x NVS-25 product
1 x AD Switch DC 12V
1 x Thank You Card

PRINT

Workflow

MSRP Price

*All prices shown are a guide only. They do not include local sales taxes and may also be subject to local import duties and shipping costs. Please contact your local reseller for a quotation.
