HS-1600T

4-Channel HD/SD HDBaseT Portable Video Streaming Studio
LEGACY
Mobile Cast

4-Channel HD/SD HDBaseT Portable Video Streaming Studio

HS-1600T
LEGACY

Made for mobility. Made for the web.

Made for mobility. Made for the web.



The HS-1600T brings a new level of simplicity to production workflows. You'll set up faster and easier thanks to its portable "briefcase" design and HDBaseT Technology. And thanks to its built-in H.264 web streaming encoder, you can stream your show to virtually any CDN like YouTube and Facebook in no time.

Variety of video and audio input/output

Variety of video and audio input/output



4 video inputs (RJ-45 x 3 + HDMI x 1) and 3 video outputs (HDMI x 3)
Audio inputs: XLR Analogue x 2 + RCA Analogue (L/R) x 2

Made with HDBaseT Technology

Made with HDBaseT Technology



Camera connections typically require one cable for video, a second cable for power, and a third one for control. However, the HS-1600T is able to do all of the above using only one ethernet cable for each camera. This increase in flexibility greatly reduces setup time, and now you can mount the camera in challenging locations (like spots without nearby power outlets)



Built-in H.264 recorder for SD cards

Built-in H.264 recorder for SD cards



The HS-1600T comes with a built-in web-ready recorder. Simply insert your SD card, and you'll have video files that can be immediately uploaded to the video network of your choice or to your website.



Stream to Facebook Live, YouTube, Twitch, and more

Stream to Facebook Live, YouTube, Twitch, and more



With the built-in H.264 streaming encoder, you can stream your show to virtually any CDN including Facebook, YouTube or Twitch in no time.



Built-in camera control.

Built-in camera control.



The HS-1600T's next generation design saves you time, money, and table space with its built-in camera control interface for up to 3 Datavideo PTZ cameras. (Works with PTC-140T and PTC-150TL)



17.3'' LED Backlit Monitor

17.3'' LED Backlit Monitor



Built-in Monitor Display. 17.3” HD TFT LED backlit monitor with resolution 1920x1080 pix.

Seamlessly compatible with dvCloud

Seamlessly compatible with dvCloud





Get the most out of your streaming hardware using DVCloud. TheHS-1600T is seamlessly compatible with Datavideo’s DVCloud service.

This subscription service give you the possibility of sending your stream to multiple destinations at the same time without having to have multiple hardware encoders.

You can also record your production on the DVCloud platform in h.264 format. After recording you can directly use this recording to upload it to your favourite content platform.

Direct SRT streaming to dvCloud prevents hickups and lag in your stream, especially when using slow or unreliable internet connections or when streaming large distances (for instance to the other side of the globe). Even if your destination does not support SRT you can still stream SRT to dvCloud and go to the destination in RTMP.

For more information on DVCloud, please visit the product page or sign up directly on www.dvcloud.tv

Build a reliable SRT live streaming workflow with all Datavideo products.

Build a reliable SRT live streaming workflow with all Datavideo products.

Datavideo's wide range of encoders, cameras, and hand-carry switchers are fully supported by SRT and dvCloud. Datavideo encoders and dvCloud provide reliable streams over unreliable networks. By using a Datavideo encoder and dvCloud together, you can utilize SRT (instead of RTMP) on the initial problematic connection or "First Mile." After your video stream reaches dvCloud, you can depend on dvCloud's reliable, high-bandwidth network to deliver the stream to your favorite destinations, like Facebook and YouTube.

4-Channel HD/SD HDBaseT Portable Video Streaming Studio

COMPARE MORE PRODUCTS
Model Number
HS-1600T
Video Standard
HD & SD
Video Format
1080p 50/59.94/60Hz
1080i 50/59.94/60Hz
720p 50/59.94/60Hz
576i/p 50Hz
480i/p 59.94Hz
Input Routable / Crosspoint
----
Video Input
3 x HDBaseT
1 x HDMI
Computer Graphic Interface
1 via HDMI
Down-converted Output
Yes
Video Output
3x HDMI PGM
1x STREAM (RJ-45)
Analogue Audio Input
2x Balanced XLR
1x Stereo RCA (L/R)
De-embedded Digital Audio
Analogue Audio Output
1x Stereo headphone
Digital Embedded Audio Support
Input 2 channels, Output 2 channels
Audio Delay Calibration
----
A+V Switching
----
USK
1x USK support Lumakey
DSK
----
Picture in Picture
1
Logo Insertion
----
Title Creator
----
Built-in Audio Mixer
Yes, 4 channels
Built-in Monitor Display
17.3” HD TFT LED backlit, 1920x1080 pix
Built-in Intercom & Tally
----

Streaming

Streaming
H.264 / AVC, Main/ High Profile
Configurable Bit-rate up to 10Mbps
Streaming Audio Encode
AAC-LC
Configurable bit rate range from 32Kbps to 384Kbps
Sample rate: 48KHz, 16bit
Streaming Protocol
TS over TCP/UDP (unicast & multicast)
RTSP over HTTP/TCP/UDP (RTSP Elementary Streaming)
RTMP/RTMPS (Publish)
HLS
SRT
Streaming Control
Web browser UI for configuration and control Socket commands
Recording File System
FAT, exFAT, NTFS
Recording File Format
MP4
Streaming & Recording Setting Control
Web UI for system configuration and control

Others

Special Features
Built-in camera controller
Dimension (LxWxH)
455 x 355 x 134 mm
Weight
17.2 Lbs (7.8 kg), Reinforce Plastic Case
Power
DC 48V, 4.16A
Operating Temp. Range
0~40 °C
What's in the Box
1 x HS-1600T Product
1 x AD Switch DC 48V with AC Cord
3 x Ethernet Cable
